PIPES - TECHNICAL SPECIFICATIONS AS PER INDIAN STANDARDS


DESIGNATION & SIZE OUTER DIAMETER(0D) THICKNESS(mm) WEIGHT PER MTR (Kg) SECTIONAL AREA (cm2)
ISPIP | NB15
LIGHT 21.3 2.0 0.947 1.21
MEDIUM 21.3 2.6 1.21 1.53
HEAVY 21.3 3.2 1.44 1.82
ISPIP | NB20
LIGHT 26.9 2.3 1.38 1.78
MEDIUM 26.9 2.6 1.56 1.98
HEAVY 26.9 3.2 1.87 2.38
ISPIP | NB25
LIGHT 33.7 2.6 1.98 2.54
MEDIUM 33.7 3.2 2.41 3.06
HEAVY 33.7 4.0 2.93 3.73
ISPIP | NB32
LIGHT 42.4 2.6 2.54 3.25
MEDIUM 42.4 3.2 3.10 3.94
HEAVY 42.4 4.0 3.79 4.82
ISPIP | NB40
LIGHT 48.3 2.9 3.23 4.13
MEDIUM 48.3 3.2 3.56 4.53
HEAVY 48.3 4.0 4.37 5.56
ISPIP | NB50
LIGHT 60.3 2.9 4.08 5.23
MEDIUM 60.3 3.6 5.03 6.41
HEAVY 60.3 4.5 6.19 7.88
ISPIP | NB65
LIGHT 76.1 3.2 5.71 7.32
MEDIUM 76.1 3.6 6.42 8.20
HEAVY 76.1 4.5 7.93 10.1
ISPIP | NB80
LIGHT 88.9 3.2 6.72 8.61
MEDIUM 88.9 4.0 8.36 10.7
HEAVY 88.9 4.8 9.90 12.7
ISPIP | NB90
LIGHT 101.6 3.6 8.70 11.1
MEDIUM 101.6 4.0 9.63 12.3
HEAVY 101.6 4.8 11.5 14.6
ISPIP | NB100
LIGHT 114.3 3.6 9.7 12.5
MEDIUM 114.3 4.5 12.2 15.5
HEAVY 114.3 5.4 14.5 18.5
ISPIP | NB110
LIGHT 127 4.5 13.6 17.3
MEDIUM 127 4.4 14.5 18.4
HEAVY 127 5.4 16.2 20.6
ISPIP | NB125
LIGHT 139.7 4.5 15.0 19.1
MEDIUM 139.7 4.8 15.9 20.3
HEAVY 139.7 5.4 17.9 22.8
ISPIP | NB135
LIGHT 152.4 4.5 16.4 20.9
MEDIUM 152.4 4.8 17.5 22.2
HEAVY 152.4 5.4 19.6 25.0
ISPIP | NB150
LIGHT 165.1 4.5 17.8 22.7
MEDIUM 165.1 4.8 18.9 24.2
HEAVY 165.1 5.4 21.3 27.1
ISPIP | NB150
LIGHT 168.3 4.5 18.2 23.1
MEDIUM 168.3 4.8 19.4 24.7
HEAVY 1 168.3 5.4 21.7 27.6
HEAVY 1 168.3 6.3 25.2 32.0
ISPIP | NB175
LIGHT 193.7 4.8 22.4 28.5
MEDIUM 193.7 5.4 25.1 32.0
HEAVY 193.7 5.9 27.3 34.8
ISPIP | NB200
LIGHT 219.1 4.8 25.4 32.3
MEDIUM 219.1 5.6 29.5 37.5
HEAVY 219.1 5.9 31.0 39.5
ISPIP | NB225
HEAVY 244.5 5.9 34.7 44.2
ISPIP | NB250
HEAVY 273.0 5.9 38.9 49.5
ISPIP | NB300
HEAVY 323.9 6.3 49.3 62.8
ISPIP | NB350
HEAVY 355.6 8.0 68.6 87.3
